Quick VOA Response Time Fiberhome Fonst3000 VMU48E With Variable Optical Attenuator

Product Categories

Guangdong Global Telecommunication Technology Co., Ltd.

Contact Now

Name: Quick VOA Response Time Fiberhome Fonst3000 VMU48E With Variable Optical Attenuator
Brand: Fiberhome
Price: 1 USD

Brand Name : Fiberhome

Model Number : FONST 3000 VMU48_E

Certification : ISO9001

Place of Origin : China

MOQ : 1 pc

Price : To be negotiated

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000 units

Delivery Time : 2-4 working week

Packaging Details : Wooden Carton, Export Carton

Type : 48 Ch Optical Multiplexer Card with Variable Optical Attenuator

Dimensions (H × W) (mm) : 368 × 60

Net Weight (kg) : 1.8

Power Consumption : 40 w

Contact Now

Quick VOA Response Time Fiberhome Fonst3000 VMU48E With Variable Optical Attenuator

Overview

Interface Specifications

Item	Unit	Specification
Ripple	dB	≤ 0.75
Adjacent channel isolation	dB	≥ 25
Non-adjacent channel isolation	dB	≥30
Integrated cross interference	dB	≥22
-1 dB spectrum width	nm	≥0.4
-20 dB spectrum width	nm	≤ 1.2
Central wavelength shift	nm	±0.05
VOA attenuation range	dB	0-10
VOA response time	ms	≤ 10
VOA attenuation accuracy	dB	±0.8
power-off attenuation value	dB	≥10
Note 1: This item is the test value when the VOA attenuation value is set to 0dB. The VOA attenuation value of each channel is set to 0dB by default before delivery, and users can adjust the value according to the project requirement in practise.

Mechanical Parameters

Card	Panel Dimensions (H × W) (mm)	Net Weight (kg)
VMU48	368 × 60	1.8

Power Consumption

Card	Maximum Power Consumption (W)
VMU48_E	40
